-33%

SPM6KL

APC BY SCHNEIDER ELECTRIC | SPM6KL

Original price was: $1,599.00.Current price is: $1,067.59.

USD

AED

JPY

EUR

KRW

GBP

RUB

INR

MNT

IRR

THB

AUD

SGD

PHP

LAK

MYR

VND

In stock

SKU： SPM6KL Categories： UPS Systems, Schneider SP

Product Highlights

Description

APC BY SCHNEIDER ELECTRIC | SPM6KL

Specification

datesheet
Specifications
SP Series UPS, 6KVA Tower Extended Runtime
SPM6KL
Summary
Lead Time	Usually delivered within 6 weeks
Main Information
Main Input Voltage	220 volts
Product Type	Uninterruptible Power Supply (UPS)
Other Input Voltage	230 V 240 V
Main Output Voltage	220 V 230 V 240 V
Other Output Voltage	230 V 240 V
Rated Power [W]	6000 W
Rated Power [VA]	6000 VA
Output Connector Type	Hardwired 3-wire (H N + E) 1
Battery Type	External Battery System
Included Accessories	Basic UPS Signaling RS-232 cable 1 DC cable Software CD User Manual USB cable
Product Series	Easy UPS On-Line
	Battery and Runtime
Other Parameters	Can be set to 220, 230, or 240 output voltage
Power Supply Voltage	240V
Auto-Detectable, Expandable Delay Time	0
Battery Charging Voltage (W)	1170 W rated
Universal
Redundant	No
	Physical Parameters
Color	Black

Width	19 cm
Depth	37.4 cm
Net Weight	13 kg
Installation Preference	No preference
Installation Type	Not rack-mountable
Installable on Double Columns	0
USB Compatibility	Yes
Input
Input Voltage Limit	110.. .300 V half load 176.. .300 V full load
Number of Input Connectors	1 hardwired 3-wire (1PH + N + G)
Network Frequency	40…70 Hz auto-sensing
Output
Bypass Type	Internal bypass (automatic or manual)
Crest Factor	3:01
Maximum Configurable Power (Volt-Amps)	6000 VA
Maximum Configurable Power (Watts)	6000 W
Topology	Double conversion online
Waveform Type	Sine wave
Power	94% (full load)
Output Frequency (Synchronized with Main Frequency)	50/60 Hz +/- 3 Hz synchronized with main frequency
Compatibility
Product Certification	CE
Environment
Sound Level	55 dBA
Operating Altitude	0…3000 m
Operating Temperature	0…40 °C
Storage Ambient Temperature	-15…60 °C
Storage Height	0…15000 m
IP Protection Rating	IP20
Relative Humidity	0…95% non-condensing
Storage Relative Humidity	0…95% non-condensing
Communication and Management
Alarm	Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm
Emergency Shutdown	Yes
Idle Slot	1
Alarm Function	Multifunction LCD display status management console.
Surge Protection and Filtering
Surge Suppression Energy Packaging Unit	600 J
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	46 cm
Package 1 Width	49.1 cm
Package 1 Length	29 cm
Package 1 Weight	16 kg
SCC14	1.07313E+13
Contract Warranty
Warranty Certificate	2-year repair or replacement
