SPM3KL

APC BY SCHNEIDER ELECTRIC | SPM3KL

Original price was: $649.79.Current price is: $592.34.

USD

AED

JPY

EUR

KRW

GBP

RUB

INR

MNT

IRR

THB

AUD

SGD

PHP

LAK

MYR

VND

In stock

SKU： SPM3KL Categories： UPS Systems, Schneider SP

Product Highlights

Description

APC BY SCHNEIDER ELECTRIC | SPM3KL

Specification

datesheet
Specifications
SP Series UPS, 3KVA Tower Extended Runtime
SPM3KL
	Summary
Lead Time Main Information	Usually in stock
Main Input Voltage	220 volts
Product Type	Uninterruptible Power Supply (UPS)
Other Input Voltage	230 V 240 V
Main Output Voltage	220 V
Other Output Voltage	230 V 240 V
Rated Power [W]	2400 W
Rated Power [VA]	3000 VA
Input Connection Type	CH2-16P China
Output Connection Type	4 Chinese outlet
Output Connector Type	Hardwired 3-wire (H N + E) 1
Cable Length	1.5 m
Cable Quantity	1
Battery Type	External battery system
Accessories	Basic UPS Signaling RS-232 cable Software CD Power cord 1 DC cable User manual USB cable
Product Series	Easy UPS On-Line
Battery and Run Time
Other Parameters	Can be set to 220, 230, or 240 output voltage
Power Supply Voltage	72 V
Auto-Detectable, Expandable Delay Time	0
Battery Charging Voltage (Watts)	350 W rated
Universal
Filled Power Module Slot Count	0
Idle Power Module Slot Count	0
Redundant Physical Parameters	No
Color	Black
Height	23.8 cm
Width	14.5 cm
Depth	40 cm
Net Weight	7.9 kg
Installation Preference	No preference
Installation Type	Not rack-mountable
Installable on Double Columns	0
USB Compatible	Yes
Input
Input Voltage Limit	110.. .300 V half load 160.. .280 V full load
Network Frequency	40…70 Hz auto-sensing
Output
Bypass Type	Internal bypass (automatic or manual)
Crest Factor	3:01
Maximum Configurable Power (Volt-Amps)	3000 VA
Maximum Configurable Power (Watts)	2400 W
Topology	Double conversion online
Waveform Type	Sine wave
Power	88 % (full load)
Output Frequency (Synchronized with Main Frequency)	50/60 Hz +/- 3 Hz synchronized with main frequency
Compatibility
Product Certification	CE
Environment
Sound Level	50 dBA
Operating Altitude	0…3000 m
Operating Temperature	0…40 °C
Storage Ambient Temperature	-20…50 °C
Storage Height	0…15000 m
IP Protection Class	IP20
Relative Humidity	0…95 % non-condensing
Storage Relative Humidity	0…95 % non-condensing
Communication and Management
Alarm	Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm
Idle Slot	1
Alarm Function	Multifunction LCD display status management console.
Surge Protection and Filtering
Surge Suppression Energy	600 J
Packaging Unit
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	33 cm
Package 1 Width	47.7 cm
Package 1 Length	23.5 cm
Package 1 Weight	9.6 kg
SCC14	1.07313E+13
Contract Warranty
Warranty Certificate	2 years repair or replacement
