-17%

SPM1K

SCHNEIDER SMART-UPS ON-LINE SPM1K（SPM1K）

Original price was: $400.00.Current price is: $332.50.

USD

AED

JPY

EUR

KRW

GBP

RUB

INR

MNT

IRR

THB

AUD

SGD

PHP

LAK

MYR

VND

In stock

SKU： SPM1K Categories： UPS Systems, Schneider SP

Product Highlights

Description

SCHNEIDER SMART-UPS ON-LINE SPM1K（SPM1K）

Specification

Product parameter table
Specifications
SP series U PS, 1KVA tower marking machine
SPM1K.
Essentials
Delivery Date Main Information	Usually available in stock
Main Input Voltage	220 volts
Product type	Uninterruptible power supply (UPS)
Other Input Voltage	230 V 240 V
.Main Output Voltage.	220 V
Other Output Voltage	230 V 240 V
Rated power [W]	800 W.
Rated power [VA]	1000 VA.
Input Connection Type	CH1-10P Ch ina.
Output connection type	.3ch in that outlet
Cable length	1.5 m
Number of cables	1
Battery type	Lead-acid battery
Attached equipment	Basic UPS signaling RS-232 cable software CD power cable user manual USB cable
Product series	Easy UPS On-L ine
Battery and running time
Other parameters	.It can be set to 220, 230 or 240 output voltage
Power supply voltage	24 V
Automatic detection and expandable delay time	0
Typical charging time	4 hours
Battery service life	3…5 years
Battery charging voltage (watts)	30 W rated.
Be commonly used
Maximum running time	4 minutes
Redundancy	Number
Physical parameters
Color	Black
Height	23.3 cm
Width	14.5 cm
Depth	28.8 cm
Product weight	9.3 kg
.Installation preferences	No prefer nee
Installation type	Not rack-mou ntable
Can be installed on double columns	0
USB compatible	Yes
Input
Input voltage limit	110.. .300 V half load 160.. .280 V full load
Network frequency	40…70 Hz auto-se nsing
Send out
Type of bypass	Internal bypass (automatically manual)
Wave peak coefficient	3:1
Maximum configurable power (voltammetry)	1000 VA.
Maximum configurable power (watts)	800 W.
Topography	Double conversion online
Waveform type	Sine wave
Power	88% (full load)
.Output frequency (synchronized with the main frequency)	50/60 Hz +/- 3 Hz is synchronized with the main frequency
Consistency
Product certification	CE.
Environment
Sound level	50 dBA
Working altitude	0…3000 m
Operating temperature	0…40 °C
Storage environment temperature	-20…50 °C
Storage height	.0…15000 m
IP protection level	IP20.
Relative humidity	0…95% non-condensation
Store relative humidity	0…95% non-condensation
Communication and management
Alarm	Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm
Alarm function surge protection and filtering	Multi-functional LCD display status management console.
Surge inhibits energy	600 J
Packaging unit
Unit Type of Package 1	PCE.
Number of Units in Package 1	1
Package 1 Height	33 cm
Package 1 Width	36.5 cm
Package 1 Length	23.5 cm
Package 1 Weight.	10.9 kg
SCC14.	10731304343179
Contract warranty
Warranty	Repair or replacement within 2 years
